启动接口，分配IP地址：
router>
router> enable
router#
router# configure terminal
router(config）#
router(config）# interface Type Port
router(config-if）# no shutdown
router(config-if）# ip address IP-Address Subnet-Mask
router(config-if）# ^z
配置RIP路由协议：30秒更新一次
router(config）# router rip
router(config-if）# network Network-Number <–通告标准A,B,C类网–>
router(config-if）# ^z
配置IGRP路由协议：90秒更新一次
router(config）# router igrp AS-Number <– AS-Number范围1~65535–>
router(config-if）# network Network-Number <–通告标准A,B,C类网–>
router(config-if）# ^z
配置Novell IPX路由协议：Novell RIP 60秒更新一次
router(config）# ipx routing [node address]
router(config）# ipx maximum-paths Paths <–设置负载平衡，范围1~512–>
router(config）# interface Type Port
router(config-if）# ipx network Network-Number [encapsulation encapsulation-type] [secondary] <–通告标准A,B,C类网–>
router(config-if）# ^z
配置DDR:
router(config）# dialer-list Group-Number protocol Protocol-Type permit [list ACL-Number]
router(config）# interface bri 0
router(config-if）# dialer-group Group-Number
router(config-if）# dialer map Protocol-Type Next-Hop-Address name Hostname Telphone-Number
router(config-if）# ^z
配置ISDN:
router(config）# isdn swith-type Swith-Type <–配置ISDN交换机类型，中国使用basic-net3–>
router(config-if）# ^z
配置Frame Relay:
router(config-if）# encapsulation frame-relay [cisco | ietf ]
router(config-if）# frame-relay lmi-type [ansi | cisco | q933a ]
router(config-if）# bandwidth kilobits
router(config-if）# frame-relay invers-arp [ Protocol ] [dlci ]
<–配置静态Invers ARP表：
router(config）# frame-relay Protocol Protocol-Address DLCI [ Broadcast ] [ ietf | cisco ] [ payload-compress | packet-by-packet ]
–>
<–设置Keepalive间隔：
router(config-if）# keepalive Number
–>
<–为本地接口指定DLCI:
router(config-if）# frame-lelay local-dlci Number
–>
<–子接口配置：
router(config-if）# interface Type Port.Subininterface-Number [ multipoint | point-to-point ]
router(config-subif）# ip unnumbered Interface
router(config-subif）# frame-lelay local-dlci Number
–>
router(config-if）# ^z
配置标准ACL:
router(config）# access-list Access-List-Number [ permit | deny ] source [ source-mask ] <– Access-List-Number 范围：1~99标准ACL;100~199扩展ACL;800~899标准IPX ACL;900~999扩展IPX ACL;1000~1099 IPX SAP ACL;600~699Apple Talk ACL–>
router(config）# interface Type Port
router(config-if）# ip access-group Access-List-Number [ in | out ]
router(config-if）# ^z
配置扩展ACL:
router(config）# access-list Access-List-Number [ permit | deny ] [ Protocol | Protocol-Number ] source source-wildcard [ Source-Port ] destination destination-wildcard [ Destination-Port ] [ established ]
router(config）# interface Type Port
router(config-if）# ip access-group Access-List-Number [ in | out ]
router(config-if）# ^z
配置命名ACL:
router(config）# ip access-list [ standard | extended ] ACL-Name
router(config [ std- | ext- ] nacl）# [ permit | deny ] [ IP-Access-List-Test-Conditions ]
router(config [ std- | ext- ] nacl）# no [ permit | deny ] [ IP-Access-List-Test-Conditions ]
router(config [ std- | ext- ] nacl）# ^z
router(config）# interface Type Port
router(config-if）# ip access-group [ACL-Name | 1~199 ] [ in | out ]
router(config-if）# ^z
配置DCE时钟：
router# show controllers Type Port <–确定DCE接口–>
router(confin-if）# clock rate 64000 <–进入DCE接口设置时钟速率–>
router(config-if）# ^z
配置PPP协议：
router(config）# username Name password Set-Password-Here <–验证方建立数据库–>
router(config）# interface Type Port
router(config-if）# encapsulation ppp <–启动PPP协议–>
router(config-if）# ppp outhentication [ chap | chap pap | pap chap | pap ] <–选择PPP认证–>
router(config-if）# ppp pap sent-username Name password Password <–发送验证信息–>
router(config-if）# ^z
