IPv4路由基础配置与静态路由(配置ipv4静态路由和默认路由)

背景：

AR1、AR2、AR3来自3个不同的网络(网段)并且分别为自己网络的网关，通过静态路由配置实现各网络之间的互通，当AR1>AR2线路中断时能够将流量自动切换到AR1>AR3>AR2路线进行访问。

拓扑：

步骤一：

查看3台设备是否已经配置IP地址

display ip interface brief命令是用来查看接口与IP相关的简要信息，包括IP地、子网掩码、物理状态、协议状态等处于不同状态的接口数目等。

system-view #其他两台设备均为此命令查看，这里就不在详述。 [AR1]display ip interface brief

*down: administratively down ^down: standby (l): loopback (s): spoofing The number of interface that is UP in Physical is 3 The number of interface that is DOWN in Physical is 1 The number of interface that is UP in Protocol is 1 The number of interface that is DOWN in Protocol is 3 Interface IP Address/Mask Physical Protocol GigabitEthernet0/0/0 unassigned up down GigabitEthernet0/0/1 unassigned up down GigabitEthernet0/0/2 unassigned down down NULL0 unassigned up up(s)

IP Address/Mask 显示为unassigned则表示该接口未配置地址

步骤二：

配置设备与终端互联的IP地址以及PC终端地址

AR1：

system-view [AR1]interface GigabitEthernet 0/0/0 [AR1-GigabitEthernet0/0/0]ip address 10.1.12.1 24 [AR1]interface GigabitEthernet 0/0/1 [AR1-GigabitEthernet0/0/1]ip address 10.1.13.1 24 [AR1-GigabitEthernet0/0/2]ip address 1.1.1.1 24

AR2:

system-view [AR2]interface GigabitEthernet 0/0/0 [AR2-GigabitEthernet0/0/0]ip address 10.1.12.2 24 [AR2]interface GigabitEthernet 0/0/1 [AR2-GigabitEthernet0/0/1]ip address 10.1.23.2 24 [AR2-GigabitEthernet0/0/2]ip address 2.2.2.1 24

AR3:

system-view [AR3]interface GigabitEthernet 0/0/0 [AR3-GigabitEthernet0/0/0]ip address 10.1.13.3 24 [AR3]interface GigabitEthernet 0/0/1 [AR3-GigabitEthernet0/0/1]ip address 10.1.23.3 24 [AR3-GigabitEthernet0/0/2]ip address 3.3.3.1 24

步骤三：

查看物理接口地址是否配置成功

[AR1]display ip interface brief *down: administratively down ^down: standby (l): loopback (s): spoofing The number of interface that is UP in Physical is 4 The number of interface that is DOWN in Physical is 0 The number of interface that is UP in Protocol is 4 The number of interface that is DOWN in Protocol is 0 Interface IP Address/Mask Physical Protocol GigabitEthernet0/0/0 10.1.12.1/24 up up GigabitEthernet0/0/1 10.1.13.1/24 up up GigabitEthernet0/0/2 1.1.1.1/24 up up NULL0 unassigned up up(s) [AR2]display ip interface brief *down: administratively down ^down: standby (l): loopback (s): spoofing The number of interface that is UP in Physical is 4 The number of interface that is DOWN in Physical is 0 The number of interface that is UP in Protocol is 4 The number of interface that is DOWN in Protocol is 0 Interface IP Address/Mask Physical Protocol GigabitEthernet0/0/0 10.1.12.2/24 up up GigabitEthernet0/0/1 10.1.23.2/24 up up GigabitEthernet0/0/2 2.2.2.1/24 up up NULL0 unassigned up up(s) [AR3]display ip interface brief *down: administratively down ^down: standby (l): loopback (s): spoofing The number of interface that is UP in Physical is 4 The number of interface that is DOWN in Physical is 0 The number of interface that is UP in Protocol is 4 The number of interface that is DOWN in Protocol is 0 Interface IP Address/Mask Physical Protocol GigabitEthernet0/0/0 10.1.13.3/24 up up GigabitEthernet0/0/1 10.1.23.3/24 up up GigabitEthernet0/0/2 3.3.3.1/24 up up NULL0 unassigned up up(s)

步骤四：

测试各网段的连通性，在此以AR1为例。

[AR1]ping 10.1.12.2 PING 10.1.12.2: 56 data bytes, press CTRL_C to break Reply from 10.1.12.2: bytes=56 Sequence=1 ttl=255 time=40 ms Reply from 10.1.12.2: bytes=56 Sequence=2 ttl=255 time=30 ms Reply from 10.1.12.2: bytes=56 Sequence=3 ttl=255 time=20 ms Reply from 10.1.12.2: bytes=56 Sequence=4 ttl=255 time=30 ms Reply from 10.1.12.2: bytes=56 Sequence=5 ttl=255 time=20 ms --- 10.1.12.2 ping statistics --- 5 packet(s) transmitted 5 packet(s) received 0.00% packet loss round-trip min/avg/max = 20/28/40 ms

[AR1]ping 10.1.13.3 PING 10.1.13.3: 56 data bytes, press CTRL_C to break Reply from 10.1.13.3: bytes=56 Sequence=1 ttl=255 time=60 ms Reply from 10.1.13.3: bytes=56 Sequence=2 ttl=255 time=20 ms Reply from 10.1.13.3: bytes=56 Sequence=3 ttl=255 time=20 ms Reply from 10.1.13.3: bytes=56 Sequence=4 ttl=255 time=20 ms Reply from 10.1.13.3: bytes=56 Sequence=5 ttl=255 time=20 ms --- 10.1.13.3 ping statistics --- 5 packet(s) transmitted 5 packet(s) received 0.00% packet loss round-trip min/avg/max = 20/28/60 ms

步骤五：

查看AR1的路由表

[AR1]display ip routing-table Route Flags: R - relay, D - download to fib ------------------------------------------------------------------------------ Routing Tables: Public Destinations : 13 Routes : 13 Destination/Mask Proto Pre Cost Flags NextHop Interface 1.1.1.0/24 Direct 0 0 D 1.1.1.1 GigabitEthernet 0/0/2 1.1.1.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/2 1.1.1.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/2 10.1.12.0/24 Direct 0 0 D 10.1.12.1 GigabitEthernet 0/0/0 10.1.12.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/0 10.1.12.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/0 10.1.13.0/24 Direct 0 0 D 10.1.13.1 GigabitEthernet 0/0/1 10.1.13.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/1 10.1.13.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/1 127.0.0.0/8 Direct 0 0 D 127.0.0.1 InLoopBack0 127.0.0.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0 127.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0 255.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0

大家可以看到，当接口地址配置完成之后，针对每个接口IP地址会自动生成3条直连路由。

步骤六：

测试PC1与PC2之间的连通性

PC>ping 2.2.2.5 Ping 2.2.2.5: 32 data bytes, Press Ctrl_C to break Request timeout! Request timeout! Request timeout! Request timeout! Request timeout! --- 2.2.2.5 ping statistics --- 5 packet(s) transmitted 0 packet(s) received 100.00% packet loss

使用Ping命令来指定发送ICMP echo-request报文，此时由于路由器上没有到达该目的IP的路由条目，所以无法Ping通PC2。

步骤七：

在AR1上配置到达AR2和AR3的PC网段的路由条目

ip route-static 2.2.2.5 24 10.1.12.2 ip route-static 3.3.3.5 24 10.1.13.3

查看AR1的路由表

[AR1]dis ip routing-table Route Flags: R - relay, D - download to fib ------------------------------------------------------------------------------ Routing Tables: Public Destinations : 15 Routes : 15 Destination/Mask Proto Pre Cost Flags NextHop Interface 1.1.1.0/24 Direct 0 0 D 1.1.1.1 GigabitEthernet 0/0/2 1.1.1.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/2 1.1.1.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/2 2.2.2.0/24 Static 60 0 RD 10.1.12.2 GigabitEthernet 0/0/0 3.3.3.0/24 Static 60 0 RD 10.1.13.3 GigabitEthernet 0/0/1 10.1.12.0/24 Direct 0 0 D 10.1.12.1 GigabitEthernet 0/0/0 10.1.12.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/0 10.1.12.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/0 10.1.13.0/24 Direct 0 0 D 10.1.13.1 GigabitEthernet 0/0/1 10.1.13.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/1 10.1.13.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/1 127.0.0.0/8 Direct 0 0 D 127.0.0.1 InLoopBack0 127.0.0.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0 127.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0 255.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0

此时查看标红处我们配置的静态路由已经加入到了AR1的路由表中。

此时我们再次测试PC1是否能与PC2互通

PC1>ping 2.2.2.5 Ping 2.2.2.5: 32 data bytes, Press Ctrl_C to break Request timeout! Request timeout! Request timeout! Request timeout! Request timeout! --- 2.2.2.5 ping statistics --- 5 packet(s) transmitted 0 packet(s) received 100.00% packet loss

大家可以看到，我们虽然写了去往PC2的静态路由但是还是无法通信，原因就是数据包去往PC2后他无法将数据包返回到我们PC1的接口，静态路由是需要我们将两端的双向路由都要写进各自的路由表中，这样我们才能通信。

此时我们将AR2也添加上去往PC1的路由再来试试。

[AR2]ip route-static 1.1.1.5 24 10.1.12.1

查看我们的AR2的路由表中是否存在去往AR1中PC网关的路由条目。

[AR2]display ip routing-table Route Flags: R - relay, D - download to fib ------------------------------------------------------------------------------ Routing Tables: Public Destinations : 14 Routes : 14 Destination/Mask Proto Pre Cost Flags NextHop Interface 1.1.1.0/24 Static 60 0 RD 10.1.12.1 GigabitEthernet 0/0/0 2.2.2.0/24 Direct 0 0 D 2.2.2.1 GigabitEthernet 0/0/2 2.2.2.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/2 2.2.2.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/2 10.1.12.0/24 Direct 0 0 D 10.1.12.2 GigabitEthernet 0/0/0 10.1.12.2/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/0 10.1.12.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/0 10.1.23.0/24 Direct 0 0 D 10.1.23.2 GigabitEthernet 0/0/1 10.1.23.2/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/1 10.1.23.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/1 127.0.0.0/8 Direct 0 0 D 127.0.0.1 InLoopBack0 127.0.0.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0 127.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0 255.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0

标红处我们可以看到AR2的路由表中存在去往PC1的路由，那么这个时候我们再去看下PC1能否Ping通PC2。

PC1>ping 2.2.2.5 Ping 2.2.2.5: 32 data bytes, Press Ctrl_C to break Request timeout! From 2.2.2.5: bytes=32 seq=2 ttl=126 time=15 ms From 2.2.2.5: bytes=32 seq=3 ttl=126 time=16 ms From 2.2.2.5: bytes=32 seq=4 ttl=126 time=31 ms From 2.2.2.5: bytes=32 seq=5 ttl=126 time=32 ms --- 2.2.2.5 ping statistics --- 5 packet(s) transmitted 4 packet(s) received 20.00% packet loss round-trip min/avg/max = 0/23/32 ms

这个时候我们就可以看到PC1与PC2互通了。

步骤八：

我们将剩余的路由条目完成配置

[AR2]ip route-static 1.1.1.5 24 10.1.12.1 [AR2]ip route-static 3.3.3.5 24 10.1.23.3 [AR3]ip route-static 1.1.1.5 24 10.1.13.1 [AR3]ip route-static 2.2.2.5 24 10.1.23.2

PC1>ping 3.3.3.5 Ping 3.3.3.5: 32 data bytes, Press Ctrl_C to break Request timeout! From 3.3.3.5: bytes=32 seq=2 ttl=126 time=31 ms From 3.3.3.5: bytes=32 seq=3 ttl=126 time=31 ms From 3.3.3.5: bytes=32 seq=4 ttl=126 time=16 ms From 3.3.3.5: bytes=32 seq=5 ttl=126 time=31 ms --- 3.3.3.5 ping statistics --- 5 packet(s) transmitted 4 packet(s) received 20.00% packet loss round-trip min/avg/max = 0/27/31 ms

此时我们3台终端都能成功互相访问了。

步骤九：

我们查看AR1和AR2的链路没断开之前路由的走向

tracert命令只要用于查看数据包从源端到目的端的路径信息。

PC1>tracert 2.2.2.5 traceroute to 2.2.2.5, 8 hops max (ICMP), press Ctrl+C to stop 1 1.1.1.1 16 ms <1 ms 15 ms 2 *10.1.12.2 32 ms 15 ms 3 *2.2.2.5 16 ms 31 ms

标红处下一跳是AR2的接口地址，说明此时走的是主路线。

配置PC1到PC2的备份路由

[AR1]ip route-static 2.2.2.5 24 10.1.13.3 preference 100 [AR2]ip route-static 1.1.1.5 24 10.1.23.3 preference 100

我们在查看AR1和AR2的路由表

[AR2]dis ip routing-table Route Flags: R - relay, D - download to fib ------------------------------------------------------------------------------ Routing Tables: Public Destinations : 15 Routes : 15 Destination/Mask Proto Pre Cost Flags NextHop Interface 1.1.1.0/24 Static 60 0 RD 10.1.12.1 GigabitEthernet 0/0/0 2.2.2.0/24 Direct 0 0 D 2.2.2.1 GigabitEthernet 0/0/2 2.2.2.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/2 2.2.2.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/2 3.3.3.0/24 Static 60 0 RD 10.1.23.3 GigabitEthernet 0/0/1 10.1.12.0/24 Direct 0 0 D 10.1.12.2 GigabitEthernet 0/0/0 10.1.12.2/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/0 10.1.12.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/0 10.1.23.0/24 Direct 0 0 D 10.1.23.2 GigabitEthernet 0/0/1 10.1.23.2/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/1 10.1.23.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/1 127.0.0.0/8 Direct 0 0 D 127.0.0.1 InLoopBack0 127.0.0.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0 127.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0 255.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0

我们可以看到AR1和AR2的路由表中并没有存在刚刚配置的备份路由条目

这个时候我们关闭AR1>AR2互联的接口

[AR1]int GigabitEthernet 0/0/0 [AR1-GigabitEthernet0/0/0]shutdown

在查看AR1和AR2的路由表

[AR1]dis ip routing-table Route Flags: R - relay, D - download to fib ------------------------------------------------------------------------------ Routing Tables: Public Destinations : 12 Routes : 12 Destination/Mask Proto Pre Cost Flags NextHop Interface 1.1.1.0/24 Direct 0 0 D 1.1.1.1 GigabitEthernet 0/0/2 1.1.1.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/2 1.1.1.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/2 2.2.2.0/24 Static 100 0 RD 10.1.13.3 GigabitEthernet 0/0/1 3.3.3.0/24 Static 60 0 RD 10.1.13.3 GigabitEthernet 0/0/1 10.1.13.0/24 Direct 0 0 D 10.1.13.1 GigabitEthernet 0/0/1 10.1.13.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/1 10.1.13.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/1 127.0.0.0/8 Direct 0 0 D 127.0.0.1 InLoopBack0 127.0.0.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0 127.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0 255.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0

[AR2]dis ip routing-table Route Flags: R - relay, D - download to fib ------------------------------------------------------------------------------ Routing Tables: Public Destinations : 12 Routes : 12 Destination/Mask Proto Pre Cost Flags NextHop Interface 1.1.1.0/24 Static 100 0 RD 10.1.23.3 GigabitEthernet 0/0/1 2.2.2.0/24 Direct 0 0 D 2.2.2.1 GigabitEthernet 0/0/2 2.2.2.1/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/2 2.2.2.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/2 3.3.3.0/24 Static 60 0 RD 10.1.23.3 GigabitEthernet 0/0/1 10.1.23.0/24 Direct 0 0 D 10.1.23.2 GigabitEthernet 0/0/1 10.1.23.2/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/1 10.1.23.255/32 Direct 0 0 D 127.0.0.1 GigabitEthernet 0/0/1 127.0.0.0/8 Direct 0 0 D 127.0.0.1 InLoopBack0 127.0.0.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0 127.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0 255.255.255.255/32 Direct 0 0 D 127.0.0.1 InLoopBack0

标红处我们可以看到刚刚配置的备份路由(浮动静态路由)在接口shutdown时，原先的路由失效，优先级低的路由出现了。

这个时候我们在用tracert命令进行追踪数据包看去往PC2的流量是否切换到AR3的路线。

PC1>tracert 2.2.2.5 traceroute to 2.2.2.5, 8 hops max (ICMP), press Ctrl+C to stop 1 1.1.1.1 15 ms 16 ms 16 ms 2 10.1.13.3 15 ms 32 ms 15 ms 3 *10.1.23.2 31 ms 16 ms 4 *2.2.2.5 31 ms 16 ms

标红处我们可以看到当主路线断开以后备份路由(浮动静态路由)自动生效接替了主线路的路由，到此所有配置结束，备份路由(浮动静态路由)在我们实际生产环境中用途很广泛，大家可以在使用过程中灵活搭配其他路由协议来进行配置。

结束：

感谢大家的观看！到这里我们的文章就结束了，以上就是IPv4路由基础配置与静态路由的讲解，更多内容请大家关注个人公众号：ytwbyg
